Phụ tùng thay thế cho cấu hình cá nhân hóa.
Kỹ thuật chi tiết:
Màn hình STN chế độ DP màu xanh
Kích thước: 6 inch
Giao thức: MPI/PROFIBUS DP
Giao diện: RS485/RS422/USB
Khe cắm giao diện máy in cho MMC
Có thể cấu hình bằng WinCC flexible 2005
Lợi ích cho khách hàng:
Cung cấp tính linh hoạt trong kết nối thiết bị.
Hỗ trợ thay thế dễ dàng cho các hệ thống hiện có.
Giúp tối ưu hóa quy trình vận hành với giao tiếp hiệu quả.
Tiết kiệm thời gian và chi phí bảo trì hệ thống.
Additional Information
Support
| Technical Data
| Manuals / Links
|
####
| FEATURE | VALUE |
| Number of HW-interfaces other | 0 |
| Radio standard GPRS | false |
| Type of display | STN |
| Process default value (input) possible | true |
| Supporting protocol for SERCOS | false |
| Supporting protocol for INTERBUS-Safety | false |
| Voltage type (supply voltage) | DC |
| Supporting protocol for PROFINET IO | false |
| Supporting protocol for AS-Interface Safety at Work | false |
| IO link master | false |
| Number of HW-interfaces RS-232 | 0 |
| Supporting protocol for LON | false |
| Supporting protocol for PROFIBUS | true |
| Supporting protocol for Data-Highway | false |
| Supporting protocol for SafetyBUS p | false |
| With message indication | true |
| With SW interfaces | false |
| Screen diagonal | 5.7 inch |
| Number of HW-interfaces USB | 1 |
| Supporting protocol for KNX | false |
| Supporting protocol for EtherNet/IP | true |
| Number of interfaces PROFINET | 0 |
| Supporting protocol for Foundation Fieldbus | false |
| Degree of protection (IP), front side | IP65 |
| Operating temperature | 0 °C |
| Supporting protocol for DeviceNet | false |
| Supporting protocol for SUCONET | false |
| Supporting protocol for DeviceNet Safety | false |
| Number of HW-interfaces industrial Ethernet | 0 |
| Suitable for safety functions | false |
| Wall mounting/direct mounting | false |
| Supporting protocol for INTERBUS | false |
| Number of pixels, horizontal | 320 |
| Number of HW-interfaces RS-422 | 1 |
| Number of HW-interfaces parallel | 0 |
| Number of pixels, vertical | 240 |
| With alpha numeric keyboard | true |
| Height of the front | 156 mm |
| Number of HW-interfaces wireless | 0 |
| Radio standard UMTS | false |
| Width of the front | 212 mm |
| With printer output | true |
| Number of HW-interfaces serial TTY | 0 |
| Number of grey-scales/blue-scales of display | 4 |
| Useful project memory/user memory | 2048 kByte |
| Additional software components, loadable | true |
| With message system (incl. buffer and confirmation) | true |
| Number of HW-interfaces RS-485 | 1 |
| With numeric keyboard | true |
| Radio standard WLAN 802.11 | false |
| Supporting protocol for CAN | false |
| Built-in depth | 44 mm |
| Supporting protocol for TCP/IP | true |
| Supply voltage DC | 20.4 V |
| Number of colours of the display | 4 |
| Process value representation (output) possible | true |
| Radio standard GSM | false |
| Supply voltage DC | 28.8 V |
| Supporting protocol for PROFINET CBA | false |
| Number of online languages | 5 |
| With recipes | true |
| Supporting protocol for other bus systems | true |
| Rail mounting possible | false |
| Colour display | false |
| Operating temperature | 50 °C |
| Radio standard Bluetooth | false |
| Supporting protocol for ASI | false |
| Supporting protocol for Modbus | true |
| Supporting protocol for PROFIsafe | false |
| Number of password levels | 50 |
