Màn hình cảm ứng STN chế độ DP màu xanh SIMATIC OP 177B 6″ cho cấu hình cá nhân hóa.
Thông tin chi tiết kỹ thuật:
ID sản phẩm: 109486162
Giao thức: MPI/PROFIBUS DP
Giao diện: RS485/RS422/USB
Khe cắm giao diện máy in cho MMC
Cấu hình bằng WinCC flexible 2005
Chỉ có sẵn dưới dạng phụ tùng thay thế
Lợi ích cho khách hàng:
Cải thiện khả năng tương tác với hệ thống tự động hóa.
Hỗ trợ nhiều giao thức kết nối khác nhau.
Dễ dàng cấu hình với phần mềm WinCC flexible 2005.
Chuẩn bị cho nhu cầu nâng cấp hệ thống trong tương lai.
Additional Information
Support
| Technical Data
| Manuals / Links
|
####
| FEATURE | VALUE |
| Additional software components, loadable | true |
| IO link master | false |
| Radio standard GSM | false |
| Suitable for safety functions | false |
| Process default value (input) possible | true |
| Supporting protocol for CAN | false |
| Number of buttons with LED | 26 |
| Supporting protocol for ASI | false |
| Supporting protocol for Modbus | true |
| Height of the front | 212 mm |
| Supporting protocol for EtherNet/IP | true |
| Number of grey-scales/blue-scales of display | 4 |
| Built-in depth | 45 mm |
| Wall mounting/direct mounting | false |
| Number of HW-interfaces USB | 1 |
| Width of the front | 243 mm |
| Number of pixels, horizontal | 320 |
| Number of colours of the display | 4 |
| Process value representation (output) possible | true |
| Number of HW-interfaces wireless | 0 |
| Supporting protocol for AS-Interface Safety at Work | false |
| Supporting protocol for INTERBUS | false |
| Radio standard GPRS | false |
| Supporting protocol for TCP/IP | true |
| With alpha numeric keyboard | true |
| Number of online languages | 5 |
| Number of password levels | 50 |
| With recipes | true |
| Supporting protocol for Foundation Fieldbus | false |
| Supporting protocol for other bus systems | true |
| Screen diagonal | 5.7 inch |
| Number of pixels, vertical | 240 |
| Supply voltage DC | 28.8 V |
| Operating temperature | 0 °C |
| Type of display | STN |
| With SW interfaces | false |
| Supporting protocol for DeviceNet | false |
| With numeric keyboard | true |
| Supporting protocol for DeviceNet Safety | false |
| Number of HW-interfaces RS-232 | 0 |
| With message indication | true |
| Supporting protocol for PROFINET IO | false |
| Supporting protocol for SUCONET | false |
| Radio standard Bluetooth | false |
| Number of HW-interfaces RS-485 | 1 |
| With message system (incl. buffer and confirmation) | true |
| Number of HW-interfaces other | 0 |
| Number of HW-interfaces industrial Ethernet | 0 |
| Supporting protocol for SafetyBUS p | false |
| Supporting protocol for PROFIsafe | false |
| Radio standard WLAN 802.11 | false |
| Supporting protocol for SERCOS | false |
| Supporting protocol for Data-Highway | false |
| Supporting protocol for PROFIBUS | true |
| Number of function buttons, programmable | 32 |
| Supporting protocol for KNX | false |
| Number of HW-interfaces serial TTY | 0 |
| With printer output | true |
| Colour display | false |
| Rail mounting possible | false |
| Number of interfaces PROFINET | 0 |
| Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces RS-422 | 1 |
| Operating temperature | 50 °C |
| Supply voltage DC | 20.4 V |
| Useful project memory/user memory | 2048 kByte |
| Supporting protocol for INTERBUS-Safety | false |
| Voltage type (supply voltage) | DC |
| Degree of protection (IP), front side | IP65 |
| Supporting protocol for LON | false |
| Supporting protocol for PROFINET CBA | false |
| Radio standard UMTS | false |
